Shibaura Machine Series - BSF-150C

AEROSPACE - POWER GENERATION - MARINE - CONSTRUCTION

This medium / large floor type horizontal milling and boring machine has been designed for maximum operational rigidity, flexibility and high metal removal, coupled with speed and accuracy . This high performance machine can be equipped with a choice of automated accessories such as facing heads, universal heads and long reach snouts, these helping to eliminate unnecessary set-up changes and making best use of manpower.

High rapid and feed traverse rates, coupled with a choice of spindle speeds, also help in optimising machine performance. For work loading, a selection or combination of floor plates, moving rotary tables and pallet changers is available. Independent heavy duty horizontal and vertical indexers can also be fitted, working in conjunction with the machine through the CNC control to present the workpiece in any angle and position for machining.

The power, rigidity and machining performance of the BF150 with its square ram, capable of handling loads up to 130 tons, makes it suitable for use in industries such as power generation, aerospace, construction and marine, where high accuracy and long term reliability are paramount.

Principal: Shibaura Machine

Series: Horizontal Boring Machines

Product: BSF-150C

Spindle Speed 3,000rpm

Rapid Traverse 20M/min

Machining Feedrate 6M/min

Spindle Taper BT50

Tool Storage Capacity > 120
