The H Series of high-speed bridge mills comprises of six models. Exceptional rigidity is achieved by 4-6 roller blocks per guideway and the headstocks have been designed shorter and lighter to decrease deflection. The top roof cover has sliding sections for ease of overhead part loading and the H6 has a 30,000rpm spindle for high speed machining using small diameter tools.
Travel (X, Y, Z) 1020 x 700 x 500 mm
Table Size 1050 x 700 mm
Table Capacity 800 kg
Spindle 15,000 rpm / BBT40
ATC > 40
Rapid Traverse Rate (X, Y, Z) 30 / 30 / 30 m/min
Weight 9100 kg
